Description
Features
- Configurable settings allow the pump to be custom-tailored to best suit the hospital’s needs.
- Computer control capability allows remote control or monitoring of the pump via a standard RS232-C interface.
- Pumps a wide variety of fluids, including blood and fat emulsions.
- Suitable for use in epidural administration.
- Safety clamp automatically occludes the tubing when the pump door is open.
- Occlusion sensors detect both upstream and downstream restrictions. Sensitivity of the downstream occlusion sensor is selectable through the pump’s configuration.
- Flow check display shows resistance to flow.
- Ultrasonic air-in-line detector. Sensitivity of the air detector is selectable through the pump’s configuration.
- The Programmed Delivery Profile (PDP) enables manual programming or ramped calculation of up to 10 sequential infusion programs for situations where multiple flow rates are indicated.
- Slide clamp loading option provides flow shutoff when I.V. set is removed from the pump.
- Locking control panel helps prevent patient tampering.
- An independent secondary medication program. The pump automatically switches over to the primary program upon completion.
- Volume-Time programming automatically calculates flow rate.
- Automatic self-test routine checks for proper function before use.
- Five-hour memory retains infusion data after power-off.
- Easily replaceable fuse, battery, and power cord.
Baxter Flo-Gard 6201 Volumetric Infusion Pump Specifications
- Description: Linear Peristaltic Volumetric Infusion Pump.
- Keep Vein Open (KVO) Rate: 5 mL/hr or programmed rate, whichever is less.
- Nurse Call: Available through the COMMUNICATIONS PORT.
- Battery: 12 Volt, 2.0 Ah sealed lead-acid.
- Battery Life: Approximately 6 hours with pump running at a rate from 1 to 1400 mL/hr.
- Battery Recharge: 8 hours for more than 80% recharge.
- AC Power Requirements: 110/120 V, 60 Hz.
- Power Cord: 2.9 m (9.5 ft) long, with Hospital Grade plug.
- Fuse: 0.5 A, 250 V, SB, 5.2 mm (0.20″) x 20 mm (0.79″).
- Leakage Current: Less than 50 microamps (using UL-544 specified test methods).
- Weight: 11.6 lb (5.3 kg) approximately.
- Dimensions: 5.1″ (D) x 7.9″ (W) x 11.4″ (H) (13 cm x 20 cm x 29 cm).
- Flow Rate Range:
- Primary Program: 1.0 to 99.9 mL/hr in 0.1 mL increments or 1 to 1999 mL/hr in 1 mL increments. Upper limit can be reduced by authorized service personnel.
- Secondary Program: 1.0 to 99.9 mL/hr in 0.1 mL increments or 1 to 999 mL/hr in 1 mL increments.
- VTBI Range: 1.0 to 99.9 mL in 0.1 mL increments or 1 to 9999 mL in 1 mL increments for both primary and secondary. Upper limit can be reduced by authorized service personnel.
- Ramp PDP Parameter Ranges:
- Total VTBI: Upper limit can be reduced by authorized service personnel.
- Run Time equal to or less than 16 hours: 100 to 9999 in 1 mL increments.
- Run Time greater than 16 hours: 200 to 9999 in 1 mL increments.
- Delay Time: 00:00 to 08:00 hours in minute increments.
- Run Time: 01:00 to 24:00 hours in minute increments.
- Ramp Up: 00:00 to 45% of the Run Time, in minute increments.
- Ramp Down: 00:00 to the Run Time minus Ramp Up, in minute increments.
- Total VTBI: Upper limit can be reduced by authorized service personnel.
- Air-in-Line Detection: Factory set to NORM, which causes the pump to alarm on air bubbles approximately 75 µL or larger. The MIN setting causes the pump to alarm on air bubbles approximately 50 µL or larger.
