Description

The Model ESU-2400 Electrosurgical Unit Analyzer is a high-accuracy True RMS RF

Measurement system designed to be used in the calibration and routine performance

verification of Electrosurgical Generators. It offers a higher degree of accuracy than

previously attainable with conventional Electrosurgical Unit Analyzer designs. The ESU-

2400 provides an advanced low reactance internal load bank with a range of 0 to 6400

ohms in 1 ohm increments. It is microprocessor based and utilizes a combination of

unique hardware and software to provide accurate and reliable test results, even from

difficult waveforms such as “Spray”. The DFA Technology  utilized in the ESU-2400 and

Technology  (Patent Pending) utilized in the ESU-2400H allow the system to 2 DFA

aggressively digitize the complex RF waveforms produced by Electrosurgical Generators, analyze each individual digital data point, and provide highly accurate measurement results.

The ESU-2400, unlike many conventional ESU Analyzers, has internal high voltage setup relays to control the measurement path, allowing the user to switch between Power measurements, Leakage measurements, REM/ARM/CQM testing, or even run an autosequence that could include any or all of these tests – without even moving wires around!

The current transformer internal to the ESU-2400 senses the RF current flowing through the internal test load and produces a ratiometric voltage which is digitized and analyzed by the microprocessor. Combining the standard and low ranges of the ESU-2400 with the use of the current transformer, the user has full control over the ability to get high accuracy and high resolution readings from all types of Electrosurgical Generators.

The following are highlights of some of the main features:

• TRUE RMS READINGS USING DFA TECHNOLOGY

• INDUSTRY STANDARD CURRENT SENSING TECHNOLOGY

• mV, mV PEAK, mA, CREST FACTOR AND POWER (WATTS)

RANGES, LOAD VOLTAGE(ESU-2400H only)

• COLOR QVGA DISPLAY WITH TOUCHSCREEN

• 1% OF READING MEASUREMENT ACCURACY

• DIGITAL CALIBRATION – NO POTS TO TURN

• SELECTABLE DISPLAY OPTIONS

• GRAPHICAL ON-SCREEN REPRESENTATION OF MEASURED RF SIGNAL

• HIGH RANGE (1000 mV) AND LOW RANGE (100 mV) WITH AUTOSCALING CAPABILITY

• PULSED RF WAVEFORM MEASUREMENT MODE FOR LOW DUTY CYCLE PULSED OUTPUTS OFFERED BY SOME ELECTROSURGICAL MANUFACTURERS

•  PROGRAMMABLE AUTOSEQUENCES

• PROGRAMMABLE LOAD CURVES

• BUILT IN CQM TESTING WITH ONE OHM RESOLUTION

• TISSUE RESPONSE TESTING WITH GRAPHING CAPABILITY

•  FOOTSWITCH OUTPUTS FOR TRIGGERING THE DUT

• ON-SCREEN DISPLAY OF MEASURMENT CONFIGURATION

• USB PORTS FOR KEYBOARD, MOUSE, PRINTER, OR FLASH DRIVE.

• ETHERNET PORT FOR INCREASED ACCESSIBILITY
