Description
The System 7550™ with ABC® Technology allows physicians to bring the art of surgery to new levels. By utilizing this full-powered electrosurgical generator featuring argon beam coagulation, surgeons are able to achieve rapid hemostasis resulting in:
- Reduced blood loss
- Reduced surgical time
- Reduced surgical plume
Because of its powerful capabilities, surgeons prefer this electrosurgical generator in a number of procedures including open, laparoscopy, and gastroenterology.
- Remote power control
- Pulse cut
- Programmable specialty modes
- Patient safety precautionary features
Conmed System 7500 Specifications
Dimensions
- Dimensions (hxwxd),cm (in) (Antechamber): 104.1 x 61 x 63.5 (41 x 24 x 25)
- Weight, kg (lb) (Display): 49.9 (109.8)
Output Power
- W @ flow rate: 2-5.5 l/min (Output Power): 10 to 39 (1-5 L/min)
- 6-10 l/min (Output Power): 40 to 150
- W @ flow rate: 4-8 l/min (Output POPowerWER): 40 to 59 (2-8 L/min) 1
- 4-10 l/min (Output Power): 80 to 150 Also 10 to 39 W @ 0.5-4 L/min.
- Marketed Since (Graphics Display): 1999
- Format (Wavelength, nm): Console
Operating Conditions
- Tempurature Range, A/C (Stirrer): 10 to 30
- Humidity range, % (Operating Conditions): 10 to 90
- Power Needed, VAC (Energy): 108
- Current, a: 12 max
- Watts (Generator): 600 max
Storage Conditions
- Temperature Range, A/C (Stirrer): -40 to +70
- Humidity range, % (Operating Conditions): 5 to 95
Alerts (Configuration)
- Audio volume, db (Alerts): 65 minimum
Argon Gas System
- Flow range, l/min (Argon Gas System): 0.1
- Filter pore size (Argon Gas System): 8 um
- Max. volume tank, l (cu ft) (Argon Gas System): 1,200 (42)
- Low-pressure alarm (Argon Gas System): At 250 psi
