Sample capacity |
96 × 0.2 mL PCR tubes, 1 PCR plate (96 wells) or up to 38 × 0.5 mL Eppendorf PCR tubes |
96 × 0.2 mL PCR tubes, 1 PCR plate (96 wells) or up to 38 × 0.5 mL Eppendorf PCR tubes |
4 slides or other matching consumables |
96 × 0.2 mL PCR vessels, 1 PCR plate (96 wells) |
96 × 0.2 mL PCR vessels, 1 PCR plate (96 wells) |
Heating technology |
Peltier elements, Triple Circuit Technology |
Peltier elements, Triple Circuit Technology |
Peltier elements, Triple Circuit Technology |
Peltier elements, Triple Circuit Technology |
Peltier elements, Triple Circuit Technology |
Temperature control mode |
Fast, Standard, Safe |
Fast, Standard, Safe |
Fast, Standard, Safe |
Fast, Standard, Safe |
Fast, Standard, Safe |
Temperature control range of the block |
4 – 99 °C |
4 – 99 °C |
4 – 99 °C |
4 – 99 °C |
4 – 99 °C |
Gradient range |
1 – 20 °C |
– |
– |
1 – 20 °C |
– |
Intuitive graphic programming |
■ |
■ |
■ |
■ |
■ |
Gradient temperature control range |
30 – 99 °C |
– |
– |
30 – 99 °C |
– |
Block homogeneity 20 – 72 °C |
≤ ±0.3 °C |
≤ ±0.3 °C |
≤ ±0.3 °C |
≤ ±0.3 °C |
≤ ±0.3 °C |
Control accuracy |
±0.2 °C |
±0.2 °C |
±0.2 °C |
±0.2 °C |
±0.2 °C |
E-mail Notification |
■ |
■ |
■ |
■ |
■ |
flexlid® concept |
■ |
■ |
■ |
■ |
■ |
2 years warranty |
■ |
■ |
■ |
■ |
■ |
Silver block |
– |
– |
– |
■ |
■ |
Gradient block |
■ |
– |
■ |
■ |
– |
Unit can control 2 other units in network |
■ |
■ |
■ |
■ |
■ |
USB port |
■ |
■ |
■ |
■ |
■ |
Block homogeneity 90 °C |
≤ ±0.4 °C |
≤ ±0.4 °C |
≤ ±0.4 °C |
≤ ±0.4 °C |
≤ ±0.4 °C |
Heating rate |
3 °C/s 2 |
3 °C/s 2 |
3 °C/s 2 |
5 °C/s 2 |
5 °C/s 2 |
Cooling rate |
2 °C/s 2 |
2 °C/s 2 |
2 °C/s 2 |
3.5 °C/s 2 |
3.5 °C/s 2 |
Gradient block |
Over 12 rows (0.2 mL) |
– |
– |
Over 12 rows (0.2 mL) |
– |
Lid descent |
flexlid® technology, with TSP |
flexlid® technology, with TSP |
flexlid® technology, with TSP |
flexlid® technology, with TSP |
flexlid® technology, with TSP |
Lid temperature range |
37 – 110 °C |
37 – 110 °C |
37 – 110 °C |
37 – 110 °C |
37 – 110 °C |
Interfaces |
CAN_in/CAN_out, Ethernet, USB |
CAN_in/CAN_out, Ethernet, USB |
CAN_in/CAN_out, Ethernet, USB |
CAN_in/CAN_out, Ethernet, USB |
CAN_in/CAN_out, Ethernet, USB |
Power supply |
115 V, 50 – 60 Hz |
115 V, 50 – 60 Hz |
110 V, 50 – 60 Hz |
110 V, 50 – 60 Hz |
110 V, 50 – 60 Hz |
Max. power consumption |
700 W |
700 W |
700 W |
540 W |
540 W |
Total weight |
10.9 kg |
10.9 kg |
10.4 kg |
10.9 kg |
10.9 kg |
Dimensions (W × D × H) |
25 × 41.2 × 32.1 cm / 9.8 × 16.2 × 12.6 in |
25 × 41.2 × 32.1 cm / 9.8 × 16.2 × 12.6 in |
25 × 41.2 × 32.1 cm |
25 × 41.2 × 32.1 cm |
25 × 41.2 × 32.1 cm |
Number of programs on device |
> 700 |
> 700 |
> 700 |
> 700 |
> 700 |
Remote Device Monitoring and Notifications (VisioNize®) |
VisioNize® box enabled |
VisioNize® box enabled |
VisioNize® box enabled |
VisioNize® box enabled |
VisioNize® box enabled |
