Description
INVIVO Precess MRI 3160 Features
The Invivo Precess MRI 3160 is a patient monitor that is MRI Compatible. The Precess MRI 3160 offers all the standard parameters; ECG, SpO2, NIBP, and EtCO2. Unlike most MRI-compatible monitors, the Invivo offers wireless capabilities for ECG and SpO2 monitoring. The Invivov Process combines wireless connectivity with radio frequency shielding and digital processing to address any challenges with monitoring the patient within the MRI environment. The system can provide monitoring for acute and continuous monitoring for all patients. The 12inch display screen can view up to 6 different waveforms at once. The Invivo offers up to 8 hours of wireless patient monitoring.
- Integral color LCD display for patient information
- Intuitive graphical user interface
- Colored waves and large numerics
- Portable 8‐hour battery
- CRD printer (optional)
- Wireless remote printing to CRD (optional)
- Simultaneous display of up to 8 parameters, and 6 waveforms and associated values
- Visual and audible alarm signals, pulse tones, and system status messages
INVIVO Precess MRI 3160r Specifications
Height
- Cart: 48.5 ± 0.5 inches (123.2 ± 1.3 cm)
- CRD: 10.4 inches (26.4 cm)
- Wireless ECG module: 4.7 inches (11.9 cm)
- Wireless SpO2 module: 5.5 inches (13.9 cm)
Width
- Cart: 17.5 ± 0.5 inches (44.5 ± 1.3 cm)/li>
- CRD: 15.3 inches (38.9 cm)
- Wireless ECG module: 2.5 inches (6.4 cm)/li>
- Wireless SpO2 module: 2.5 inches (6.4 cm)
Inspiration time (Ti)
- 0.11 to 10 s (adults)
- 0.1 to 10 s (pediatric patients, neonates)
Depth)
- Cart: 17.5 ± 0.5 inches (44.5 ± 1.3 cm)
- CRD: 4.6 inches (11.7 cm)
- Wireless ECG module: 0.91 inches (2.3 cm)
- Wireless SpO2 module: 0.91 inches (2.3 cm)
Weight
- Cart: 75 ± 0.5 lbs (34 ± 0.2 Kg)
- CRD: 20 lbs (9.1 Kg)
- Wireless ECG module: 5.4 oz (158.8 g)
- Wireless SpO2 module: 5.4 oz (158.8 g)
Printer
- Chart speed: 25 or 50 mm/second
- Number of channels: 2
- Paper type and size: Non‐grid thermal, 50 mm wide
