Description
FootSwitch 2-Pedal (5020-053)
When a handpiece is attached to the controller, the firmware senses the particular hand piece connected and programs the footswitch to operate accordingly.
NOTE: All handpieces can be set to operate in either the ON?OFF or variable speed mode by setting the specific “CONTROLLER OPTIONS” switch on the back of the controller [Reference “2.1.3.3 Switch 2(Top Portion Only)-Footswitch Mode Selection”]
Operation with the E9005 High Speed Shaver and Group 3 handpieces
-
Left Pedal- Changes the handpiece operating direction between Forward, Reverse and Oscillate.
-
Right Pedal- Activates the shaver handpiece in the selected direction.
Operation with the E9010 High Speed Drill and Group 2 Drills
-
Left Pedal- Activates the handpiece in Reverse direction.
-
Right Pedal- Activates the handpiece in the Forward direction.
NOTE: There is no oscillate mode with these drills.
Operation with Group 2 Saws and E9015 Cranial Perforator Drive
NOTE: There is no direction selection or oscillate mode while using these handpieces.
-
Left Pedal- Activates the handpiece
Right Pedal- Activates the handpiece.
