Description

MEDIUM SPEED DRILL

Specifications:

Operating Speed                                                             25,000 rpm Maximum

Maximum Speed Settings                                               1,000 to 25,000 rpm in 2,000

                                                                                         rpm increments

Torque                                                                              6 in. oz.

Bur Pull Out Force Exceeds                                            12.0 lbs. (5.4 kg.)

Warning: Place Safe/Run Slide in the “safe” position when not in use.

Always operate the Medium Speed Drill with the appropriate bur guard or

attachment. Use a bur of the appropriate length – the tip of the bur guard

should cover the safe line on the bur. Without the stabilization that the proper

guard provides, the bur can break and be propelled with great force.

Check each bur before use in the Medium Speed Drill. Never use a bent bur.

For additional information, refer to the MicroChoice Bur Guard Package

Insert, or contact Hall Surgical.

1. To insert a bur, slide the appropriate bur guard over the end of the Medium Speed

Drill. Be certain it is completely seated.

2. Twist the bur lock to the “Open” position and insert the bur to the safe line or until the bur seats completely.

3. To secure the bur, twist the bur lock until the red indicator dots are aligned in the “Lock” position.

Warning: Before each use be sure that burs are completely seated and locked in the handpiece.
