Description
SPECIFICATIONS
| Laser System | Diode-pumped solid-state |
|---|---|
| Wavelength | 532 nm |
| Pulse Duration | Pulse Duration .01-3.0 seconds |
| Pulse Rate | .05-1.0 seconds and single pulse |
| Energy Settings | 50 mW to 2500 mW out of an endo-ocular probe |
| Spot Size | 50-1000 microns with Laserlink Z-1000,50-500 microns with Converging-Optics Laserlink |
| Aiming Beam | Contrasting color,adjustable intensity 635 nm nominal, < 1.0 mW |
| Cooling System | Air-cooled |
| Power Requirements | 110 VAC,< 6A, 50/60 Hz,Single phase,220 VAC,< 3A, 50/60 Hz,Single phase |
| Dimensions (Console) | Single Port 15.2cm (6in.) x 25.4cm {lOin.) x 35.6cm {14in.) Dual Port 15.2cm (6in.) x 25.4cm (lOin.) x 37.5cm (14.5in.) |
| Weight | 8 kg or 17.5 lbs |
| Delivery Systems | Laserlink Z-1000 Slit Lamp Adaptor (for Zeiss* SL 130,30SL,20SL and 125Sl); Converging Optics Laser link, Keeler* Heine* LIO Comprehensive selection of standard, straight, curved,aspirating,illuminating and stepped endophotocoagulation probes in 20,23 and 25 gauge sizes,among others |
| Physical characteristics | Height 15.2 cm (6 in), Width 25.4 cm (10 in),Depth (Single port system) 35.6 cm (14 in), Depth (Dual port system) 37.5 cm (14.5 in), Weight 8 kg (17 lb) |
