Description
Olympus LF-2 Fiberoptic Intubation Scope
Introducing the Olympus LF-2 Fiberoptic Intubation Scope for Sale.
Compatible with single-lumen endotracheal tubes with an internal diameter of 5.0 mm or greater; double-lumen tubes 37 Fr. or greater 1.5 mm channel for easier aspiration/instillation of fluids Olympus optical technology produces high-quality images for observation Wider field of view (90°) for excellent visualization Insertion tube markers (bands) for quick determination of insertion depth Waterproof for thorough reprocessing.
The Olympus LF-2 Fiberoptic Intubation Scope provides exceptional flexibility and maneuverability for a tracheal intubation fiberscope while still maintaining the same thin diameter its predecessor, the Olympus LF-1, was known for. The Olympus LF-2 insertion tube has a combination of flexibility and stiffness for easier insertion and navigation into the trachea and easier placement of endotracheal/endobronchial tubes. A large 1.5 mm channel permits improved aspiration of secretions.
Incorporating Olympus’ advanced optics along with a 90° field of view, the LF-2 provides excellent image quality and visualization to make it easier for you to quickly and successfully perform flexible tracheal intubation.
Olympus LF-2 Endoscope Fiberscope Features
- Compatible with single-lumen endotracheal tubes with an internal diameter of 5.0 mm or greater; double-lumen tubes 37 Fr. or greater
- 1.5 mm channel for easier aspiration/instillation of fluids
- Olympus optical technology produces high-quality images for observation
- Wider field of view (90°) for excellent visualization
- Insertion tube markers (bands) for quick determination of insertion depth
- Waterproof for thorough reprocessing
Olympus LF-2 Fiberoptic Intubation Scope Specifications
- Optical System
- Field of View: 90°
- Direction of View: Forward
- Depth of Field: 3 to 50 mm
- Insertion Tube
- Distal End Outer Diameter: 3.8 mm
- Insertion Tube Outer Diameter: 4.0 mm
- Working Length: 600 mm
- Instrument Channel
- Inner Channel Diameter: 1.5 mm
- Bending Section
- Angulation Range: Up 120° | Down 120°
- Total Length: 830 mm
