Description

Product Overview

This product is used in combination with the AW channel cleaning adapter, leak tester and

chemical tank to provide the following functions.

1. This product can be combined with the AW channel cleaning adapter to drain water from

the OES scope and EVIS scope air and water channel.

2. This product can be combined with the leak tester to test OES scopes and EVIS scopes

for water leaks by applying air pressure to the interior of the scopes and then submerging them in water to look for an air bubbles.

3. This product can be combined with the AW channel cleaning adapter and chemical tank to feed rubbing alcohol into the OES scope and EVIS scope air and water channel in order to dry them

Features

1. This product simplifies draining water from the OES scope and EVIS scope air and water pipelines. (AW channel cleaning adapter)

2. This product simplifies the water leak tests for the OES scope and EVIS scope. (Using the leak tester.)

3. The product can be installed on a wall near a sink with the included hanger.

4. This product can be installed on the left or right side of a sink.

5. This product simplifies feeding rubbing alcohol into the OES scope and EVIS scope air and water channel in order to dry them. (AW tube cleaning adapter, chemical tank)

Restrictions

1. OES scopes and EVIS scopes can be used.

2. Unless the AW channel cleaning adapter, leak tester and chemical tank are used, draining water from the air and water channel, leak inspections and feeding rubbing alcohol for drying the OES scope and EVIS scope are not possible.

3. In order to drain the water feeding channel, cover the water supply connector with a finger. (Same as with the former model.)

4. The ambient operation conditions are as follows:

a) Temperature: 10 to 40 ºC

b) Humidity: 30 to 85%

c) Atmospheric pressure: 700 to 1060 hPa

d) Not to be used in an atmosphere with inflammable gases.

5. The power supply conditions are as follows:

a) Rated power supply voltage: 100 V, 120 V, 220 to 240 V (according to the intended market)

b) Rated input current: 0.4 A, 0.4 A, 0.2 A

c) Frequency: 50/60 Hz

d) Allowed voltage fluctuation: ±10%

Specifications

4-1 Main Unit Specifications

4-1-1 Applicable Endoscopes

OES Scope

EVIS Scope

4-1-2 Pump Used

Electromagnetic vibrator pump

4-1-3 Air Feeding Performance

At the scope socket: 4 2.84 x 10 Pa or greater at 0 ml/min; 4 1.76 x 10 Pa or greater at 2000 ml/min;

Note: Measured at the rated power supply voltage and a room temperature of 20 to 25 ºC

4-1-4 Control Method

By turning the power switch ON/OFF.

4-1-5 Hook Installation

Can be hung down by connecting the hanger to the hook installed in a wall.

(The hook is screwed into a wall and fixed.)

4-1-6 External Dimensions

Width 85 x Height 157 x Depth 170 mm

4-1-7 Weight

1.8 kg

4-1-8 Power Supply

Voltage: 100 V, 120 V, 220 to 240 V AC

Frequency: Both 50/60 Hz

Current: 0.4A (100 V, 120 V), 0.2A (220 V to 240 V)

Voltage fluctuation rate:within ±10%

4-2 Ambient Environment

4-2-1 Ambient Temperature

10 to 40ºC

4-2-2 Relative Humidifty

30 to 85%

4-2-3 Atmospheric Pressure

700 to 1060 Pa

4-2-4 Inflammable Atmosphere

Use in an inflammable atmosphere is prohibited.
