Description

Product Description and Intended Use

The Stryker Endoscopy Model 1088 Medical Video Camera is a highdefinition camera used to capture still and video images of endoscopic surgical applications. The 1088 Medical Video Camera consists of three main components:

• the camera console

• the camera head

• the focusing coupler

The 1088 also comes with various cables, which like the other components, can be purchased together or separately

The Camera Head

The camera head connects to the camera console and captures video and photographic images, which it relays to the camera console. It features several controls that are accessible through a button control pad located on the top of the camera head.

1. Soaking Cap: Protects the cable connector during cleaning and sterilization

2. Camera Head: Captures photographic and video images, provides camera controls, and connects to a focusing coupler

3. Camera Cable

4. Cable Connector: Connects the camera head to the camera console
