Description

The Stryker Endoscopy 1188HD Medical Video Camera is a high-definition

camera used to capture still and video images of endoscopic surgical applications.

The 1188HD Medical Video Camera consists of three main components:

• Camera console (P/N 1188-010-000)

• Camera head (P/N 1188-210-105 45° cable; 1188-410-105

autoclavable; 1188-710-105 0° cable)

• C-mount coupler (P/N 1188-020-122; 1188-410-110 autoclavable)

The 1188HD also comes with various connection cables which, like the other

components, can be purchased together or separately.

Part numbers 1188-210-105 and 1188-710-105 are not intended for sale in the

The 1188HD Camera is indicated for use in general laparoscopy,

nasopharyngoscopy, ear endoscopy, sinuscopy, and plastic surgery wherever a

laparoscope/endoscope/arthroscope is indicated for use. A few examples of the

more common endoscopic surgeries are laparoscopic cholecystectomy,

laparoscopic hernia repair, laparoscopic appendectomy, laparoscopic pelvic

lymph node dissection, laparoscopically assisted hysterectomy, laparoscopic and

thorascopic anterior spinal fusion, anterior cruciate ligament reconstruction,

knee arthroscopy, shoulder arthroscopy, small joint arthroscopy, decompression

fixation, wedge resection, lung biopsy, pleural biopsy, dorsal sympathectomy,

pleurodesis, internal mammary artery dissection for coronary artery bypass,

coronary artery bypass grafting where endoscopic visualization is indicated and

examination of the evacuated cardiac chamber during performance of valve

replacement. The users of the camera are general surgeons, gynecologists, cardiac

surgeons, thoracic surgeons, plastic surgeons, orthopedic surgeons, ENT

surgeons and urologists.

There are no known contraindications.
