Description
System Overview
The Stryker CORE Powered Instrument Driver (console) provides an integrated, centrally controlled environment that promotes safe and economical surgical practice.
The console’s software provides control over system components including the console, the graphical user interface (GUI), the irrigation pump, and the connected handpieces and footswitches (see figure 1). The software’s file management capability allows you to save and store user preference sekings and have convenient access to a favorites list of the most frequently used files to improve efficiency.
The color display, with its touch sensitive screen, provides an intuitive graphical user interface that allows you to view multiple system components and set their parameters with the touch of a finger. Changes may be made rapidly, with little to no interruption during surgery.
Multiple handpieces and footswitches may be connected and operated simultaneously from a single console. Because options vary among different handpieces, the console will only display those options that are related to the connected handpiece.
An integral irrigation pump system reliably supplies coolant/irrigation to the cutting site with adjustable flow rates.
Various cutting accessories and irrigation cassettes used with the system are also recognized and identified on the console screen by means of a wireless tag technology.
Console settings, like display brightness and speaker volume, may be easily adjusted. The on board speaker provides audible feedback during operation and configuration.
The console accepts either 100 VAC – 230 VAC input and has the capability to power heavy-duty handpieces.
The Stryker Firewire Backbone (SFB) serial connection provides a serial communications channel between the console and other devices. This feature allows sofMare upgrades over a computer network.
|
Guldance and manufacturer’s declaration – electromagnetic immunity
|
|
The CORE Console REF 5400-050-000 is intended for use in the electromagnetic environment specified below. The customer or the user of the CORE Console REF 5400-050-000 should assure that it is used in such an environment.
|
|
immunity test
|
IEC 6060J test level
|
Compliance level
|
Electromagnetic environment – guldance
|
|
Electrostatic discharge (ESD)
IEC 61000-4-2
|
-t6 kV contact
z8 kV air
|
+2, y4, 16 kV contact
z2, z4, z8 kV air
|
Floors should be wood, concrete or ceramic tile. If floors are covered with synthetic material, the relative humidity should be at least 30°/».
|
|
Electrical fast transient/ burst
IEC 61000-4-4
|
-L2 kV for power supply lines
z1kV for input/output lines
|
+2 kV for power supply lines
z1 kV for input/output lines
|
Mains power quality should be that of a typical commercial or hospital environment.
|
|
Surge
IEC 61000-4-5
|
z1 kV line(s) to line(s)
z2 kV line(s) to earth
|
z0.5 and +1 kV line(s) to line(s)
11, z2 kV line(s) to earth
|
Mains power quality should be that of a typical commercial or hospital environment.
|
|
Voltage dips, short interruptions and voltage variations on power supply input lines
IEC 61000-4-11
|
<5°/» U
(>95% dip in L/,) for 0.5 cycle
40% U,
(60% dip in U )
for 5 cycles
70°/» U,
(30°/x dip in U )
for 25 cycles
<5°« U
(>95% dip in U,)
for 5 sec
|
<5°/» U
(>95% dip in L/,j
for 0.5 cycle
40% L/
(60% dip in U,)
for 5 cycles
70% U
(30°/• dip in U )
for 25 cycles
<S% U
(>95% dip in U,)
for 5 sec
|
Mains power quality should be that of a typical commercial or hospital environment. If the user of the CORE Console REF 5400-050-000 requires continued operation during power mains interruptions, it is recommended that the CORE Console REF 5400-050-000 be powered from an uninterruptible power supply Or a battery.
|
|
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
|
3 A/m
|
3 A/m
@ 50 & 60 Hz
|
Power frequency magnetic fields should be at levels characteristic of a typical location in a typical commercial or hospital environment.
|
