Description

The docking station is a quick mount/dismount base for a Dash patient

monitor. It gives the monitor easy connect/disconnect access to AC

power, the Unity Network, to a remote display, and to auxiliary devices.

When a Dash monitor is connected to the docking station, only the

docking station’s Ethernet connector is active. The Dash monitor’s

network connector remains inactive until the monitor is disconnected

from the docking station.

An optional remote display can be connected to the system for viewing on

a larger monitor, or in a separate room. The optional remote display:

Requires Dash Port 2 docking station.

Requires Dash 3000/4000 software version 5 or later.

Must be within 150 feet of the Dash monitor.
